Technical Specifications

•

  OS

  Linux

•

  CPU

  Cortex-A9, 500MHz

•

  Memory

  128MB RAM, 128MB FLASH
  128MB RAM, 256MB FLASH(Optional)
  MicroSD card (Optional, up to 32GB)

•

  Display

  2.8-inch TFT full color LCD display,
  resolution of 320*240
  Resistive Touch screen, signature capture (Optional)

•

  Wired Communication

  Dial-up Modem; Ethernet 10/100 Base T

•

  Wireless Communication (Optional)

  2G,3G,WIFI(802.11 b/g/n)

•

  Card Reader

  Mag-stripe card,
  Chip card,
  NFC

•

  Printer

  High-speed thermal printer, 32lps
  Paper roll diameter: 50mm
  Paper width: 58mm

•

  Peripheral Ports

  1 x RS232, 1 x Pinpad, 1 x USB-A (Host), 1 x MicroUSB (OTG), 1 x Line, 1 x Tel, 1 x Ethernet

•

  Card Slots

  2 SAMs 2 x SAM,1 x SIM(optional)
  1 x SAM,2 x SIM(optional)

•

  Audio

  Built-in buzzer
  Built-in Speaker,
  support audio prompt(Optional)

•

  Power Supply

  Input: 100~240VAC 50/60Hz, 0.7A
  Output: 9.0VDC, 2.5A

•

  Accessories

  Stylus (Optional)

•

  Dimensions

  190mm (L) x 82mm (W) x 68mm (H)

•

  Weight

  350g

•

  Environment

  Operating temp: 0℃～40℃
  Storage temp: -20℃～60℃
  Relative humidity: 5%～93% (Non-condensing)

•

  Certifications

  PCI PTS 5.x, EMV L1/L2/CL1 PayPass, PayWave, CE, ROHS, TQM, AMEX, Expresspay
