N950K

Android SmartPOS
with Keypad



Equipped with Physical Keypad

Equipped with a robust keypad providing intuitive key feedback for superior trading control.

Support More Application Extension

Android 12

The latest Android 12 ensures integration with
a wide range of payment applications.

Expanded Charging Options

Supports charging via DC port and Type-C port.

Various Security Certifications

Certified for various international security standards to
ensure secure payment transactions.

Accept all Payment Methods

Supports contactless, card insertion, card swipe, and code scanning payments.etc.

Multi-touch capacitive screens
Keypad designed to support the visually impaired
Exceptional printing
velocity
Multiple communication methods

Business Scenarios

Restaurant | Express | Retail | Coffee | Bar





Technical Specifications

OS
Android 12
Processor
AP: Cortex Quad-core A53, 1.4GHz
SP: ARMv7-M security core
Memory
1GB RAM, 8GB FLASH
2GB RAM, 16GB FLASH
(Optional)
Micro SD card slot up to 256GB
Display
4.5-inch TFT full color LCD display, resolution of 854 x 480, with adjustable backlight, capacitive multi-touch screen, support electronic signature
Wireless Communication
4G/3G/2G,
Wi-Fi (802.11 b/g/n/) 2.4G, Bluetooth 4.2
Wi-Fi (802.11 a/b/g/n/ac) 2.4G&5G, Bluetooth 5.0(Optional)
Positioning
GPS/BEIDOU/GLONASS
Card Reader
Magnetic Card Reader,
Smart Card Reader,
Contactless Card Reader
Camera
0.3 MP front camera, support 1D/2D code payment
2 MP autofocus rear camera with flashlight, support 1D/2D code payment
Audio
1 x Speaker, 1 x Microphone, support audio recording and media play
Keypad
Adjustable Backlight, 10 x numeric keys, 5 x function keys, 1 x power button, 1 x VOL+, 1 x VOL-
Printer
High-speed thermal printer, 80mm/s
Paper roll diameter: 40mm
Paper width: 58mm
Peripheral Ports
1 x Type C port, 1 x DC Jack
Card Slots
2 x SIM, 2 x SAM, 1 x SD
1 x SIM, 1 x eSIM, 2 x SAM, 1 x SD(Optional)
Battery
Li-ion battery, 7.2V/2600mAh/18.7Wh (Equal to 3.6V/5200mAh)
Li-ion battery, 7.2V/3300mAh/23.7Wh (Equal to 3.6V/6600mAh)(Optional)
Power Supply
Input: 100-240V AC 50/60Hz
Output: 5.0V DC, 2.0A
Docking Station
Charging base(Optional)
Dimensions
187mm (L) x 80.2mm(W) x 63mm(H)
Weight
433g including battery
Environment
Operating temperature: -10℃～50℃ (14℉~122℉)
Storage temperature: -20℃～60℃ (-4℉~140℉)
Relative humidity: 5%～93% (Non-condensing)
Certifications
EMV L1, EMV CL1, PCI 6.x, EMV L2, PayPass, PayWave, ROHS, TQM, AMEX,
QuickPass, D-PAS, ANATEL, ABECES, BIS, RUPAY
